Unified Display System For Automotives

Vehicle parameters are monitored to know the performance of the vehicle for driver asistance. Previously mechanical units are used on the dashboard to measure the performance of the vehicle and it has been improved to electromechanical units. Now a days, it is further improved to the fully electronics system with the various display technology to avoid unwanted ambient light and remove reflections, glare, back scattering and the contrast requirements in daylight to display the vehicle performance parameters . In this thesis, fully electronic driver information system with CAN communication is designed. It uses many technologies fusing display, multiplexing, CAN protocol and I2C protocol. This project deals with development of the ECU signals which are required by driver for the assistance. A testing module is developed based on the ECU signals and this module communicates with display module through CAN communication. The display used for the project is the SSFLC graphical LCD which gives good viewing angle, fast response, high contrast, high memory and low power consumption.
