Tomographic SAR Reconstruction of a 4D City using TerraSAR-X data

Bachelor Thesis from the year 2012 in the subject Engineering - Aerospace Technology, grade: 1,3, Technical University of Munich (Deutsches Zentrum für Luft- und Raumfahrt), course: Photogrammetrie und Fernerkundung, language: English, abstract: Driven by military and civilian applications, the demand of very high resolution mapping

and accurate monitoring has increased rapidly over the recent years. Nowadays, it is

possible to create 4D models involving time variations using multiple synthetic aperture

radar (SAR) images, combined with interferometric methods. SAR has evolved to satisfy

a variety of applications for civilian and military users, for example by supporting

catastrophe management, detection of geological changes, monitoring large construction

sites or mines. With the help of SAR data obtained from the TerraSAR-X satellite, infrastructural

monitoring is made possible from a distance. The benefit of this is that

potential collapse within mines or tunnels could be prevented. Concrete degradation that

could lead to building collapse, endangering people¿s lives can also be identified before

any catastrophe has the chance to occur.

Currently, Tomographic SAR (TomoSAR) is the most advanced and competent interferometric

SAR (InSAR) method in the area of urban monitoring. TomoSAR makes

monitoring in 4D possible by creating the 3D position with the motion parameters.

This thesis applies a new TomoSAR technique and method, developed by ZHU and her

colleagues, 2012 [1], on a very high resolution (VHR) spotlight data stack in the area of

Berlin. The images were taken by the TerraSAR-X satellite (Germany) over a timeframe

of 3 years. The result is a 3D point cloud of the observed area, with the velocity of linear

motion and the amplitude of periodic motion.

The result of the work that forms the basis for this thesis, is the realization of high

deformation and motion in Berlin¿s infrastructure, especially around Berlin¿s main station,

on bridges (¿ Überflieger Brücke¿) and railways - often up to 10mm.
