Linear Integrated Circuits Laboratory Manual

Linear Integrated Circuits are the foundation of all analog electronic system design. This manual consists of various experiments based on OPAMP circuits and is useful for the undergraduate students of electrical, electronics engineering as well as science students. The manual is divided into four parts. 1. Basic experiments on Amplifiers 2. Practical Limitations of OPAMP 3. OPAMP applications and 4. Course Information. All the experiments have the appropriate theory, derivations, procedure, working circuits, a place for students to write observations and conclusions. It also has provision for faculty to do the assessment of each experiment using the outcome-based approach. The Course information part of the manual has course outcomes, program outcomes, the lab plan and assessment plan which will be useful to faculty. It also has laboratory instructions for safety. The manual is useful for conducting the lab sessions of OPAMP based courses. This manual is based on Outcome Based Education Principles.
