Linear Integrated Circuit Question Set

The book contains: current mirror and current sources, Current sources as active loads, Voltage sources, Voltage References, BJT Differential amplifier with active loads, Basic information about op-amps ¿ Ideal Operational Amplifier ¿ General operational amplifier stages and internal circuit diagrams of IC 741, DC and AC performance characteristics, slew rate, Open and closed loop configurations ¿ JFET Operational Amplifiers ¿ LF155 and TL082. Sign Changer, Scale Changer, Phase Shift Circuits, Voltage Follower, V-to-I and I-to-V converters, adder, subtractor, Instrumentation amplifier, Integrator, Differentiator, Logarithmic amplifier, Antilogarithmic amplifier, Comparators, Schmitt trigger, Precision rectifier, peak detector, clipper and clamper, Low-pass, high-pass and band-pass Butterworth filters.
