Flight Operating Instructions for X-5 Airplane

An outgrowth of the Third Reich's Emergency Fighter Program, the Messerschmitt P.1101 jet fighter featured a radical new design in which the sweep of the wing could be altered in flight. Captured by the Allies before it could be completed, the P.1101 was sent to the United States where it inspired the Bell X-5. Produced by a team led by Robert J. Wood, the X-5 was a true "variable geometry" platform that offered in-flight wing positions of 20°, 40°, and 60°. Far more complex than the P.1101, the X-5 utilized a jackscrew to move the wings along horizontal rails, and disc brakes to lock the wing into position.

Two X-5s were built, and almost 200 flights were made between 1951 and 1955. While the design initially showed promise, the X-5 had a tendency to go into a violent spin. That characteristic led to the crash of the second prototype in 1953, an accident that killed test pilot Capt. Ray Popson. The accident led to the cancellation of tentative plans to mass produce a modified design as a low-cost tactical fighter. Still, the X-5 successfully demonstrated the utility of a swept-wing design, and inspired a whole generation of aircraft from the F-111 and F-14 to the B-1.

Originally produced in 1951 by the United States Air Force and NACA, this flight operating handbook was originally restricted. It has now been declassified and made available in its entirety. Please note, due to the age and rarity of this manual, some images may be substandard.
