Design And Implementation of 4X2 Compressors Using New XNOR Modules: Design of Ultra Low Power Compressors

Design And Implementation of 4X2 Compressors Using New XNOR Modules: Design of Ultra Low Power Compressors

von Pardhu Thottempudi
Taschenbuch - 9783659851605
39,90 €
  • Versandkostenfrei
  • Hinweis: Print on Demand. Lieferbar innerhalb von 7 bis 10 Tagen
  • inkl. MwSt. & Versandkosten (innerhalb Deutschlands)
  • Hinweis: Print on Demand. Lieferbar innerhalb von 7 bis 10 Tagen
  • inkl. MwSt. & Versandkosten (innerhalb Deutschlands)

Autorenfreundlich Bücher kaufen?!

Beschreibung

I present a new design for a 1-bit fUll adder featuring hybrid-CMOS design style. My approach achieves low-energy operations in 90nm technology. Hybrid-CMOS design style makes use of various CMOS Iogic style circuits to build new ull adders with desired specifcations. The new SERF- full adder (FA) circuit optimized for ultra low power operation is based on modifed XOR gates with clock gating to minimize the power consumption. And also generales full-swing outputs simultaneously. The new full-adder circuit successfuUy operates at low voltages with excellent signal integrity. The new adder displayed better power and delay metrics as compared to the standard ull adders. To evalºate the performance of the new full adder in a real circuit, we realized 4-2,5-2,5-3,7-2,11-2,15-4,31-5 compressors which are basically used in multiplier modules of DSP filters. Simulated results using 90nm standarad CMOS technology are provided. The simulation results show a 5% - 20% reduction in power and delay for frequency 50MHz and supply voltages range of 1.1 v.

Details

Verlag LAP Lambert Academic Publishing
Ersterscheinung März 2016
Maße 220 mm x 150 mm x 5 mm
Gewicht 136 Gramm
Format Taschenbuch
ISBN-13 9783659851605
Auflage Nicht bekannt
Seiten 80
