CCTV Closed Circuit Television for use in hydroelectric power stations

This work will show the fundamentals of structured cabling, the physical media used for the installation of Closed Circuit Television systems. In this particular work, it will be used for the installation of a Small Hydroelectric Power Station located between the towns of Pinhal da Serra and Barracão, in the north of Rio Grande do Sul, Brazil. Structured cabling is already commonly used in offices and small businesses. Its aim is to establish a standard installation, regardless of manufacturer, and to offer the user the possibility of expansion as well as ease of physical changes without loss of speed and data, Based on this concept, we can use structured cabling for the installation of a Closed Circuit Television system, as it will offer the user security for the data being transmitted, in this case images, with the possibility of adding new points, i.e. cameras, without the need for new cabling. Twisted pair metal cables and fibre optics will be used to connect the components, both of which achieve the same objectives.
