An Investigation of Naphthalenediimides as Central Building Blocks in Model Compounds for Scanning Tunneling Microscope Induced Light Emission Experiments and Förster Resonance Energy Transfer Studies

Scanning tunnelling microscopy (STM) is a powerful technique to observe surfaces at the atomic

level. The resolution of this STM technique is good enough to study the electronic properties of single

molecules adsorbed onto metallic substrates. An important step towards controllable single molecular

technologies is the determination of how the molecule-substrate interaction changes the local

molecular electronic structure. Since this electronic structure of molecules is strongly perturbed by the

electrons of the underlying metallic substrate, an electronic decoupling of the molecules from the

metal surface is required to isolate the electronic properties of an individual molecule.

Förster resonance energy transfer (FRET) has found many applications in different fields of science,

because it allows the determination of the distance between two chromophores in the 1-10 nm range.

In addition to other factors, this energy transfer is also dependent on the relative orientation of donor

and acceptor chromophores to each other.

This thesis describes the design, synthesis and investigations of model compounds for:

1). STM induced light emission experiments from single molecules and

2). for FRET studies.

Chapter 1 provides an introduction to cyclophanes, energy transfer and scanning tunnelling

microscopy.

Chapter 2 gives a description of the aims of this work, which is split into the synthesis of cyclophanes

for STM induced luminescence investigations and FRET studies. The later is complemented by the

synthesis of a linear NDI system.

Chapter 3 describes the design, synthesis and characterisation of all model compounds. In the first half

STM investigations are presented and the electronic structure of two cyclophanes and complexation

studies of the crown ether model compound are discussed. In the second half a modular synthetic route

to asymmetric N,N¿-naphthalenediimides is presented for FRET studies.

Chapter 4 gives a summary of this thesis and presents a short outlook.

Chapter 5 provides the synthesis and characterisation of all the compounds listed in this thesis and

experimental details for STM investigations.
