Beschreibung
The electrical characteristic of bipolar transistor are studied using gummel plot focusing on gain of the structure. For high speed considerations we are analyzing the small signal model using scattering parameters. The gain of this work is approximate to 200 means high gain represents low leakages in the structure. The scattering parameters describe the high speed considerations. And gummel plot describes the currents verses base emitter voltage in common emitter configuration. In this graph we didn't get any leakages but other effects are shown. The gain plot is constant for 0.5V from 0.3V to 0.8V. This proposed BJT is used in advanced processors of high speed considerations and integrated circuits.
A graduate useful study
Details
| Verlag | LAP LAMBERT Academic Publishing |
| Ersterscheinung | 17. Oktober 2016 |
| Maße | 22 cm x 15 cm x 0.8 cm |
| Gewicht | 191 Gramm |
| Format | Softcover |
| ISBN-13 | 9783659949371 |
| Seiten | 116 |
