A Computer Program for Calculating the Circular Product Dimensions

Deep drawing process is an important industrial processes where it has been extensively used. It is a process for converting the blank metal to make cylindrical shape in most of the cases. A research program for performing basic calculations related to the product shape was utilized. Eighteen geometric shapes have been selected for the production in this process. The program is include the general equations for this controlling process for each form. When choosing one of the shapes in the program, the dimensions of the desired product are selected. In other words, the inputs to the program are the required dimensions of the product before reaching the required deportation. In addition, diameter, height and other related dimension are computed which were chosen for each stage throughout the operation. Computer program is aimed to help designers templates deep drawing quickly through the implementation of the process, and this exceeds the designer experience that is required to perform the require calculations.
