Transmission lines analyzing, performance testing and implementation

The project deals with the ¿design and performance analysis of overhead transmission line model¿. The overhead transmission line classified into short, medium and long transmission lines. The types above are generally defined in this project. So that it is so difficult to implement tests on the overhead transmission line because of the length and the high voltage used in the transmission line. The optimal solution, in this case, is designing a transmission line model. The project presents a new method to design and analysis of the transmission line model by using a software computer program (MultiSim). In this project, we selected a transmission line and calculated its parameters. After that, we scaled these parameters to be the line model parameters. In this project, the computer program (MultiSim) used to the simulated and analysis of the transmission line and line model to calculate the efficiency and voltage regulation of the transmission line and line model. And perform different tests online model.
